UNIVERSAL MICROCONTROLLER TRAINER

SCOPE OF LEARNING:

Study of Microcontrollers
8051 Microcontroller
PIC 16F877 Microcontroller
AVR ATMEGA32 Microcontroller

Description

TECHNICAL SPECIFICATIONS:

Power Supplies:
DC Power Supply IC Regulated +12V, +5V DC, 250mA.
Operated on Mains power 230V, 50Hz +10%

Programmer (Separately):
PIC Kit 2 For PIC Microcontroller (USB)
Programmer for AVR (USB)
Programmer For 8051 (USB)

Application On Board.
2 Bit Optically Coupled Relay Interface.
Buzzer.
Stepper Motor With Driver.
8 Bit Led Display.
8 Bit Slide Switch.
4 Multiplexed Seven Segment Display.
DS1307 RTC
24C64 EEPROM
4 Bit Push Switch
16×2 LCD.
ADC 0808
DAC 0804
RS232 Interface (Serial Communication)
8X5 Led Matrix Display.
4X4 Keyboard.

SALIENT FEATURES:
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Instruction manual, CD Software and Programs, RS232 Cable.
Connections are brought out through 10 Pin FRC Male Connectors.
Connection Cable 10 Pin FRC.
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 12”x10”

OPTIONAL ACCESSORIES:
No
