VERIFICATION OF INDUCTOR IN SERIES AND PARLLEL
SCOPE OF LEARNING:
VERIFICATION OF INDUCTOR IN SERIES AND PARALLEL
Description
TECHNICAL SPECIFICATIONS:
Analog Meters:
Voltmeter 10V
Ammeter 50mA
Power Supplies:
DC Power Supply 0-10V DC, 150mA.
Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
Inductor 4 Different Types.
Voltage Control through Potentiometer
SALIENT FEATURES:
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Instruction manual.
Connections are brought out through 4mm Colored Sockets.
Patch Cords 4mm.
The trainer is housed in Metal Cabinet.
Size of the trainer set 10”x8”
OPTIONAL ACCESSORIES:
Multimeter
