DIAC CHARACTERISTICS TRAINER (ANLOG)
Name of Experiment: Characteristics of DIAC
Description
SPECIFICATIONS:
Analog Meters:
Ammeter 2.5mA/25mA DC.
Voltmeter 50V DC.
Power supplies:
DC Supply IC Regulated 0-50V DC, 150mA.
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Components are mounted on the panels are:
DIAC DB3
Voltage Control through Potentiometer.
Salient Features:
Instruction manual.
Operated on Mains power 230V, 50Hz.
Patch Cords 4mm.
Supply provided through the 3 pin computer socket with appropriate fuse
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 10”x8”
