RC PHASE OSCILLATOR TRAINER (USING -OP-AMP)
Name of Experiment :
Study and Construction of RC Phase Shift Oscillator
Description
TECHNICAL SPECIFICATIONS:
Power Supplies:
DC Power Supply IC Regulated +15V DC, 150mA.
Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
741 Op-Amp
Resistors
Capacitors
Variable Resistor
Output Performance Approximate
SALIENT FEATURES:
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Instruction manual.
Connections are brought out through 4mm Colored Sockets.
Patch Cords 4mm.
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 10”x8”
OPTIONAL ACCESSORIES:
CRO
