Medical Microscope for Science Lab
DSS-0002
Description
Stand
Stable & Robust, traditional Horse Shoe base.
Body
Inclined through 90 deg, standard tube length of 160 mm
Focusing
Separate coarse and fine focusing knobs with graduation on one side. Coarse movement by Rack & Pinion and Fine movement by screw lever Mechanism.
Mechanical Stage
For X-Y movements, works on dovetail slides. (other stages also available)
Nosepiece
Triple revolving Nosepiece is provided with positive click stop for proper centering.
Stage
Fixed square stage 125 x 125 mm with stage clips to hold the slide.
Illumination
Illumination tyhrough a 50 mm diameter plano concave mirror mounted on gimbal mount.
Objective
Two Achromatic Objectives of 10x & 40x (SL), 100x (Oil, SL)
Eyepieces
Two Huygenian Eyepiece of 6x, 10x, or 15x
Condenser
Moveable condenser is provided with iris diaphragm having 1.2 N.A.
